VMware vSphere 7.0 Update 1 | vCenter, ESXi, vSAN | Information
VMware announced the GA Releases of the following:
- VMware vCenter 7.0 Update 1
- VMware ESXi 7.0 Update 1
- VMware vSAN 7.0 Update 1
See the base table for all the technical enablement links, now including VMworld 2020 OnDemand Sessions
.
| Release Overview |
| vCenter Server 7.0 Update 1 | ISO Build 16860138
ESXi 7.0 Update 1 | ISO Build 16850804 VMware vSAN 7.0 Update 1 | Build 16850804 |
| What’s New vCenter Server | |
Inclusive terminology: In vCenter Server 7.0 Update 1, as part of a company-wide effort to remove instances of non-inclusive language in our products, the vSphere team has made changes to some of the terms used in the vSphere Client. APIs and CLIs still use legacy terms, but updates are pending in an upcoming release.
|
|
| Upgrade/Install Considerations vCenter | |
| Before upgrading to vCenter Server 7.0 Update 1, you must confirm that the Link Aggregation Control Protocol (LACP) mode is set to enhanced, which enables the Multiple Link Aggregation Control Protocol (the multipleLag parameter) on the VMware vSphere Distributed Switch (VDS) in your vCenter Server system.
If the LACP mode is set to basic, indicating One Link Aggregation Control Protocol (singleLag), the distributed virtual port groups on the vSphere Distributed Switch might lose connection after the upgrade and affect the management vmknic, if it is on one of the dvPort groups. During the upgrade precheck, you see an error such as Source vCenter Server has instance(s) of Distributed Virtual Switch at unsupported lacpApiVersion. For more information on converting to Enhanced LACP Support on a vSphere Distributed Switch, see VMware knowledge base article 2051311. For more information on the limitations of LACP in vSphere, see VMware knowledge base article 2051307. Product Support Notices
|
|
| What’s New ESXi | |
What’s New
|
|
| Upgrade/Install Considerations ESXi | |
| In vSphere 7.x, the Update Manager plug-in, used for administering vSphere Update Manager, is replaced with the Lifecycle Manager plug-in. Administrative operations for vSphere Update Manager are still available under the Lifecycle Manager plug-in, along with new capabilities for vSphere Lifecycle Manager.
The typical way to apply patches to ESXi 7.x hosts is by using the vSphere Lifecycle Manager. For details, see About vSphere Lifecycle Manager and vSphere Lifecycle Manager Baselines and Images. You can also update ESXi hosts without using the Lifecycle Manager plug-in, and use an image profile instead. To do this, you must manually download the patch offline bundle ZIP file from the VMware download page or the Product Patches page and use the esxcli software profile command. |
|
| What’s New vSAN | |
| vSAN 7.0 Update 1 introduces the following new features and enhancements:
Scale Without Compromise
Simplify Operations
Note: vSAN 7.0 Update 1 improves CPU performance by standardizing task timers throughout the system. This change addresses issues with timers activating earlier or later than requested, resulting in degraded performance for some workloads. |
|
| Upgrade/Install Considerations vSAN | |
| For instructions about upgrading vSAN, see vSAN Documentation Upgrading the vSAN Cluster Before You Upgrade Upgrading vCenter Server Upgrading Hosts
Note: Before performing the upgrade, please review the most recent version of the VMware Compatibility Guide to validate that the latest vSAN version is available for your platform. vSAN 7.0 Update 1 is a new release that requires a full upgrade to vSphere 7.0 Update 1. Perform the following tasks to complete the upgrade: 1. Upgrade to vCenter Server 7.0 Update 1. For more information, see the VMware vSphere 7.0 Update 1 Release Notes. Note: vSAN retired disk format version 1.0 in vSAN 7.0 Update 1. Disks running disk format version 1.0 are no longer recognized by vSAN. vSAN will block upgrade through vSphere Update Manager, ISO install, or esxcli to vSAN 7.0 Update 1. To avoid these issues, upgrade disks running disk format version 1.0 to a higher version. If you have disks on version 1, a health check alerts you to upgrade the disk format version. Disk format version 1.0 does not have performance and snapshot enhancements, and it lacks support for advanced features including checksum, deduplication and compression, and encryption. For more information about vSAN disk format version, see KB2145267. Upgrading the On-disk Format for Hosts with Limited Capacity During an upgrade of the vSAN on-disk format from version 1.0 or 2.0, a disk group evacuation is performed. The disk group is removed and upgraded to on-disk format version 13.0, and the disk group is added back to the cluster. For two-node or three-node clusters, or clusters without enough capacity to evacuate each disk group, select Allow Reduced Redundancy from the vSphere Client. You also can use the following RVC command to upgrade the on-disk format: vsan.ondisk_upgrade –allow-reduced-redundancy When you allow reduced redundancy, your VMs are unprotected for the duration of the upgrade, because this method does not evacuate data to the other hosts in the cluster. It removes each disk group, upgrades the on-disk format, and adds the disk group back to the cluster. All objects remain available, but with reduced redundancy. If you enable deduplication and compression during the upgrade to vSAN 7.0 Update 1, you can select Allow Reduced Redundancy from the vSphere Client. Limitations For information about maximum configuration limits for the vSAN 7.0 Update 1 release, see the Configuration Maximums documentation. |
|
| Technical Enablement | |
| Release Notes vCenter | Click Here | What’s New | Earlier Releases | Patch Info | Installation & Upgrade Notes | Product Support Notices |
| Release Notes ESXi | Click Here | What’s New | Earlier Releases | Patch Info | Product Support Notices | Resolved Issues | Known Issues |
| Release Notes vSAN | Click Here | What’s New | VMware vSAN Community | Upgrades for This Release | Limitations | Known Issues |
| docs.vmware/vCenter | Installation & Setup | vCenter Server Upgrade | vCenter Server Configuration |
| Docs.vmware/ESXi | Installation & Setup | Upgrading | Managing Host and Cluster Lifecycle | Host Profiles | Networking | Storage | Security
Resource Management | Availability | Monitoring & Performance |
| docs.vmware/vSAN | Using vSAN Policies | Expanding & Managing a vSAN Cluster | Device Management | Increasing Space Efficiency | Encryption
Upgrading the vSAN Cluster Before You Upgrade Upgrading vCenter Server Upgrading Hosts |
| Compatibility Information | Interoperability Matrix vCenter | Configuration Maximums vSphere (All) | Ports Used vSphere (All)
Interoperability Matrix ESXi | Interoperability Matrix vSAN | Configuration Maximums vSAN | Ports Used vSAN |
| Blogs & Infolinks | What’s New with VMware vSphere 7 Update 1 | Main VMware Blog vSphere 7 | vSAN | vSphere | vCenter Server
Announcing the ESXi-Arm Fling | In-Product Evaluation of vSphere with Tanzu vSphere 7 Update 1 – Unprecedented Scalability YouTube A Quick Look at What’s New in vSphere 7 Update 1 | vSphere with Tanzu Overview in 3 Minutes VMware vSphere with Tanzu webpage | eBook: Deliver Developer-Ready Infrastructure Using vSphere with Tanzu What’s New in vSAN 7 Update 1 | PM’s Blog, Cormac vSAN 7.0 Update 1 |
| Download | vSphere | vSAN |
| VMworld 2020 OnDemand
(Free Account Needed) |
Deep Dive: What’s New with vCenter Server [HCP1100] | 99 Problems, But A vSphere Upgrade Ain’t One [HCP1830]
Certificate Management in vSphere [HCP2050] | Connect vSAN Capacity Across Clusters with VMware HCI Mesh [DEM3206] |
| VMworld HOL Walkthrough
(VMworld Account Needed) |
Introduction to vSphere Performance [HOL-2104-95-ISM] |
Create an ESXi installation ISO with custom drivers in 9 easy steps!
Video Posted on Updated on
One of the challenges in running a VMware based home lab is the ability to work with old / inexpensive hardware but run latest software. Its a balance that is sometimes frustrating, but when it works it is very rewarding. Most recently I decided to move to 10Gbe from my InfiniBand 40Gb network. Part of this transition was to create an ESXi ISO with the latest build (6.7U3) and appropriate network card drivers. In this video blog post I’ll show 9 easy steps to create your own customized ESXi ISO and how to pin point IO Cards on the vmware HCL.
** Update 06/22/2022 ** If you are looking to do USB NICs with ESXi check out the new fling (USB Network Native Driver for ESXi) that helps with this. This Fling supports the most popular USB network adapter chipsets ASIX USB 2.0 gigabit network ASIX88178a, ASIX USB 3.0 gigabit network ASIX88179, Realtek USB 3.0 gigabit network RTL8152/RTL8153 and Aquantia AQC111U. https://flings.vmware.com/usb-network-native-driver-for-esxi
NOTE – Flings are NOT supported by VMware
** Update 03/06/2020 ** Though I had good luck with the HP 593742-001 NC523SFP DUAL PORT SFP+ 10Gb card in my Gen 4 Home Lab, I found it faulty when running in my Gen 5 Home Lab. Could be I was using a PCIe x4 slot in Gen 4, or it could be the card runs to hot to touch. For now this card was removed from VMware HCL, HP has advisories out about it, and after doing some poking around there seem to be lots of issues with it. I’m looking for a replacement and may go with the HP NC550SFP. However, this doesn’t mean the steps in this video are only for this card, the steps in this video help you to better understand how to add drivers into an ISO.
Here are the written steps I took from my video blog. If you are looking for more detail, watch the video.
Before you start – make sure you have PowerCLI installed, have download these files, and have placed these files in c:\tmp.
- Download driver –
- LSI Driver: https://my.vmware.com/group/vmware/details?downloadGroup=DT-ESXI60-QLOGIC-QLCNIC-61191&productId=491
- Note: Extract the offline bundle from this package
- Download ESXi –
- ESXi Update ZIP File: vmware.com/downloads
- Note: make sure you download the Update ZIP file and not the ESXi ISO file
I started up PowerCLI and did the following commands:
1) Add the ESXi Update ZIP file to the depot:
Add-EsxSoftwareDepot C:\tmp\update-from-esxi6.7-6.7_update03.zip
2) Add the LSI Offline Bundle ZIP file to the depot:
Add-EsxSoftwareDepot ‘C:\tmp\qlcnic-esx55-6.1.191-offline_bundle-2845912.zip’
3) Make sure the files from step 1 and 2 are in the depot:
Get-EsxSoftwareDepot
4) Show the Profile names from update-from-esxi6.7-6.7_update03. The default command only shows part of the name. To correct this and see the full name use the ‘| select name’
Get-EsxImageProfile | select name
5) Create a clone profile to start working with.
New-EsxImageProfile -cloneprofile ESXi-6.7.0-20190802001-standard -Name ESXi-6.7.0-20190802001-standard-QLogic -Vendor QLogic
6) Validate the LSI driver is loaded in the local depot. It should match the driver from step 2. Make sure you note the name and version number columns. We’ll need to combine these two with a space in the next step.
Get-EsxSoftwarePackage -Vendor q*
7) Add the software package to the cloned profile. Tip: For ‘SoftwarePackage:’ you should enter the ‘name’ space ‘version number’ from step 6. If you just use the short name it might not work.
Add-EsxSoftwarePackage
ImageProfile: ESXi-6.7.0-20190802001-standard-QLogic
SoftwarePackage[0]: net-qlcnic 6.1.191-1OEM.600.0.0.2494585
8) Optional: Compare the profiles, to see differences, and ensure the driver file is in the profile.
Get-EsxImageProfile | select name << Run this if you need a reminder on the profile names
Compare-EsxImageProfile -ComparisonProfile ESXi-6.7.0-20190802001-standard-QLogic -ReferenceProfile ESXi-6.7.0-20190802001-standard
9) Create the ISO
Export-EsxImageProfile -ImageProfile “ESXi-6.7.0-20190802001-standard-QLogic” -ExportToIso -FilePath c:\tmp\ESXi-6.7.0-20190802001-standard-QLogic.iso
That’s it! If you like my ‘no-nonsense’ videos and blogs that get straight to the point… then post a comment or let me know… Else, I’ll start posting boring video blogs!
Cross vSAN Cluster support for FT
F11 Key for nested ESXi with MAC OS X
In my home office and abroad I use a MAC Powerbook with VMware fusion quite a bit and most recently I was installing ESXi to a Fusion VM. Kindly enough the ESXi install program asked me to push F11 to continue, and when I pushed F11 my wonderful MAC translated this as the MAC function — shrink the screen.
By default, the MAC function keys are for MAC purposes vs. the standard function key they are intended. After doing a bit of searching I found two options. 1 – You can use the keypress as I described below or 2 – you can adjust your MAC settings under keyboard and uncheck “Use F1, F2, etc. keys as standard function keys”
At this point, I didn’t want to change the overall behavior of my MAC and I went with option 1. To issue the F11 key in a fusion VM simply Press FN-CMD-F11 and this allows the ESXi install to continue.
Turning a ‘No you cannot attend’ to a ‘Yes’ for VMworld
I’ve been lucky enough to make it to very VMworld since 2008 and 2014 will be my 7 time in a row. In this blog post I wanted to share with you a breakdown of some of the tips and tricks I’ve used to get to these events. Being the former Phoenix VMUG leader I’ve shared these tips with fellow VMUG users and now I’m sharing them with all of you. Users would tell me cost is the number one reason why they don’t go – “My Company sees value in this event but will not pay for it”. This breaks down to Food, Hotel, Travel, and the infamous golden ticket aka the VMworld pass. So how do users overcome the cost to attend? This is what this blog post is all about…
Working with your employer –
Having your employer pick of the tab not only benefits them as a company but yourself too. As you know VMworld is full of great content and the socialization aspects are second to none. Chances are you’ll be asked to put together a total cost to attend and this cost can be quite high for some companies on a tight budget. My suggestion is if you are getting the big ‘No’ then work with your boss around the total costs. First find out why it’s a ‘No’ and look for opportunities to overcome this. Maybe your company will pay for some of the items. Example – They might be able to cover airfare, but the rest is on you. Don’t forget if your company has a VMware TAM (Technical Account Manager) reach out them. Even if you are not directly working with the TAM they are your best resource not only for VMware Technology but for getting you to VMworld. They don’t have passes but the usually know the community very well and can assist.
Sometimes I hear “My employer will not allow me to accept gifts”. True your company may have a policy around the type of gifts you can receive and by all means follow this policy. However, keep in mind you may be able to take vacation time and represent yourself at this event not your employer. Then there is a possibility gifts could be accepted but on the premises you don’t represent your company. Some companies are okay with this but just make sure they are. If you are able to do this I would suggest you represent it as ‘personal development’.
How do I get a free VMworld Pass aka the Golden Ticket?
This can be your biggest challenge. However here are some ways to get your hands on one.
-
Give-a-ways
- I can’t tell you how many vendors have giveaways contests right now — hit them early and enter as many as you can find
-
Tips-
- When you enter, find out who your local vendor contact is and let them know you entered then stay in contact with them
- Keep in mind not all contests are the same, some are based on random drawing and others are not. This is why I say keep in contact with the vendor.
- How do I find give-a-ways >> Google ‘VMworld getting there for free’
-
Get the word out
- Tell your boss, workmates, vendors, partners, use twitter, linked in etc. and Repeat again and again. By doing this you let others know about your strong interest in getting there, in turn they might get a lead for you.
- Most importantly, reach out to your local VMUG leader and ask them for tips in your area. They are usually well connected and might have a lead for you as well.
-
Follow Twitter and Linked In – You never know who is going to post up “I have a pass and need to give it to someone” Yes that is right, before the event you can transfer a pass to someone.
- New to Twitter, need contacts? It’s simple find the #VMworld hastag, see who is posting to it and start following them. Then look at all their contacts and follow them too, soon you’ll have a gaggle of folks
- This sound like work why do all this? Simple, distributed coverage model. The more people know the more likely they are to help and in turn the more likely you’ll succeed
-
Don’t forgo an Expo-Only or Solutions Exchange Pass
- If you get offered this pass take it. I can’t tell you how many vendors have these passes and cannot give them away, seriously this is gold but folks don’t know how to leverage them.
- First off this pass has great value, there is a TON of value here
-
Second this pass can get you on to the Solutions Exchange floor where all the vendors and partners are.
- Once there start talking to all the vendors, fellow attendee, all those folks you meet on twitter, etc. as you never know who has a full pass they couldn’t get rid of, take it and upgrade yours
- Third while you are there with an Expo Pass use Twitter and the VMworld hash tags to let folks know you’re here and you are looking for a full pass.
- Stop by the VMUG booth on the Expo floor, you never know who will be there and you never know users there might be able to help you
-
Vendors and Partners
-
Find out who is sponsoring VMworld this year, and then…
- Start calling the ones you know well, ask them for support getting there
- Don’t forget to call the ones you don’t know so well too
- If you have deal on the table with a vendor coming up, inquire if they will put or through in passes, travel, etc.
-
-
Finally biting the bullet and buying a ticket
-
If you are going this route at least try to get a discount your ticket. Discounts change from year to year, so you’ll need to read the T&C’s around this. Simply google ‘vmworld discounts’
- Early Bird Pricing
- VMUG Advantage Discount
- Alumni
- VCP
- Group Discounts
-
Use PSO Credits to Pay
- Another way to pay is PSO Credits. Rules around this can change from year to year but if you plan ahead these can be a way to get to VMware.
- TIPS – Use those unused credits to pay, Are you renewing your ELA? See how you can bake in PSO credits just for VMworld
-
What about Food, Hotel, and Travel Costs?
-
Food
- There will be free food everywhere, in-fact feel free to give some to the homeless I usually do.
- If you get a pass then lunch and usually breakfast are included
- For dinner, find out where the nightly events are as they usually have food
- Talk with Vendors they might take you out, you never know
-
Hotel
- Ask a Vendor to pay for just the room or ask them to gift hotel points to you
- Room Share with someone at the event << Think about it, you won’t be in the room that often and chances are from 7AM till 10PM you’ll be out of your room
-
Use Travel sites to cut down the cost
- Secret Hotels: Carriage Inn and The Mosser. Good if you’re on a budget these fill up quickly so book ahead
- Use your Hotel or other travel points to book the hotel for free
- Get a low cost hotel away from the event, but watch your travel costs
-
Travel
-
Airfare
- Ask a vendor to pay for just the airfare, or maybe they have points they can gift you
- Use your own travel points to pay for this
-
Rideshare to the event
- See if one of your connections are driving to the event, offer to split fuel costs
- You drive someone to the event, and they pick up the hotel or vise versa
-
Local Travel
-
Use the following –
- VMworld Shuttle
- Bus
- Uber
- BART
- Once again hit up those vendors, they might have a way to get you around for free
-
-
Finally here is a breakdown of how I got to so many events and how/who paid for it….
|
Year |
Pass |
Travel |
Food |
Hotel |
|
2008 VMworld |
Vendor Sponsor – Full Pass |
Employer Paid |
Vendor / Event |
Employer Paid |
|
2009 VMworld |
VMUG Sponsored – Full Pass |
Vendor paid for Airfare with Miles |
Vendor / Event |
Employer Paid |
|
2010 VMworld |
VMUG Sponsored – Full Pass |
Vendor paid for Airfare with Miles |
Vendor / Event |
Vendor Sponsored |
|
2011 VMworld |
Vendor Sponsor – Expo Pass but I got an upgrade to Full by asking others |
I drove two others and I paid for the fuel |
Vendor / Event |
Travel Companion paid for room |
|
2012 VMworld |
Employee Labs |
Employer Paid |
Employer Paid |
Employer Paid |
|
2013 VMworld |
Employee TAM |
Employer Paid |
Employer Paid |
Employer Paid |
|
2014 VMworld |
Employee TAM |
Employer Paid |
Employer Paid |
Employer Paid |
Summing it up…
My take is, if you REALLY want to go you’ll get there but sometimes it takes effort to do so and if you do it right it might not cost you a thing. Don’t let anything stop you and find your way there.
Finally, after you’ve been to the event don’t forget about the folks who got you there and say ‘Thank you’. Then over the next year continue to build this relationship as you never know if you’ll need help again, or you want to help someone else get there.
Turning a ‘No you cannot attend’ to a ‘Yes’ for VMworld
I’ve been lucky enough to make it to every VMworld since 2008 and 2014 will be my 7th. time in a row. In this blog post I wanted to share with you a breakdown of some of the tips and tricks I’ve used to get to these events. Being the former Phoenix VMUG leader I’ve shared these tips with fellow VMUG users and now I’m sharing them with all of you. Users would tell me cost is the number one reason why they don’t go – “My Company sees value in this event but will not pay for it”. This breaks down to Food, Hotel, Travel, and the infamous golden ticket, aka the VMworld pass. So how do users overcome the cost to attend? This is what this blog post is all about…
Working with your employer –
Having your employer pick up the tab not only benefits them as a company but yourself too. As you know VMworld is full of great content and the socialization aspects are second to none. Chances are you’ll be asked to put together a total cost to attend and this cost can be quite high for some companies on a tight budget. My suggestion is if you are getting the big ‘No’ then work with your boss around the total costs. First find out why it’s a ‘No’ and look for opportunities to overcome this. Maybe your company will pay for some of the items. Example – They might be able to cover airfare, but the rest is on you. Don’t forget if your company has a VMware TAM (Technical Account Manager) reach out them. Even if you are not directly working with the TAM they are your best resource not only for VMware Technology but also for getting you to VMworld. They don’t have passes but they usually know the community very well and can assist.
Sometimes I hear “My employer will not allow me to accept gifts”. True your company may have a policy around the type of gifts you can receive and by all means follow this policy. However, keep in mind you may be able to take vacation time and represent yourself at this event not your employer. Then there is a possibility gifts could be accepted but on the premises you don’t represent your company. Some companies are okay with this but just make sure they are. If you are able to do this I would suggest you represent it as ‘personal development’.
How do I get a free VMworld Pass?
This can be your biggest challenge. However here are some ways to get your hands on one.
-
Give-a-ways
- I can’t tell you how many vendors have giveaways contests right now — hit them early and enter as many contests as you can find
-
Tips-
- When you enter, find out who your local vendor contact is and let them know you entered. Then stay in contact with them.
- Keep in mind not all contests are the same, some are based on random drawing and others are not. This is why I say keep in contact with the vendor.
- How do I find give-a-ways >> Google ‘VMworld getting there for free’
-
Get the word out
- Tell your boss, workmates, vendors, and partners. Post on Twitter, Linked-In, etc. and Repeat again and again. By doing this you let others know about your strong interest in getting there, in turn they might get a lead for you.
- Most importantly, reach out to your local VMUG leader and ask them for tips in your area. They are usually well connected and might have a lead for you as well.
-
Follow Twitter and Linked-In – You never know who is going to post up “I have a pass and need to give it to someone”. Yes that is right, before the event you can transfer a pass to someone.
- New to Twitter, need contacts? It’s a pretty simple to get started. Simply find the #VMworld hastag, see who is posting to it and start following them. Then look at all their contacts and follow them too, soon you’ll have a gaggle of folks.
- This sound like work. Why do all this? Simple, distributed coverage model. The more people know the more likely they are to help and in turn the more likely you’ll succeed
-
Don’t forgo an Expo-Only or Solutions Exchange Pass
- If you get offered this pass take it. I can’t tell you how many vendors have these passes and have trouble giving them away, seriously this is gold but folks don’t know how to leverage them.
- First off this pass has great value, there is a TON of value here.
-
Second this pass can get you on to the Solutions Exchange floor where all the vendors and partners are.
- Once there start talking to all the vendors, fellow attendee, all those folks you meet on Twitter, etc. as you never know who has a full pass they couldn’t get rid of, take it and upgrade yours.
- Third, while you are there with an Expo Pass use Twitter and the VMworld hash tags to let folks know you’re here and you are looking for a full pass.
- Stop by the VMUG booth on the Expo floor, you never know who will be there and you never know if users there might be able to help you.
-
Vendors and Partners
-
Find out who is sponsoring VMworld this year, and then…
- Start calling the ones you know well, ask them for support getting there.
- Don’t forget to call the ones you don’t know so well too.
- If you have an upcoming deal on the table with a vendor, inquire if they will throw in passes, travel, etc.
-
What about Food, Hotel, and Travel Costs?
-
Food
- There will be free food everywhere, in-fact feel free to give some to the homeless I usually do.
- If you get a pass then lunch and usually breakfast are included.
- For dinner, find out where the nightly events are as they usually have food.
- Talk with Vendors as they might take you out, you never know.
-
Hotel
- Ask a Vendor to pay for just the room or ask them to gift hotel points to you.
- Room Share with someone at the event << Think about it, you won’t be in the room that often and chances are from 7AM till 10PM you’ll be out of your room.
-
Use travel sites to cut down the cost.
- Secret Hotels: Best Western Carriage Inn and The Mosser. Good if you’re on a budget but chances are they are full this year (2014).
- Use your hotel or other travel points to book the hotel for free.
- Get a low cost hotel away from the event, but watch your travel costs.
-
Travel
-
Airfare
- Ask a vendor to pay for just the airfare, or maybe they have points they can gift you.
- Use your own travel points to pay for this.
-
Rideshare to the event
- See if one of your connections are driving to the event, offer to split fuel costs.
- You drive someone to the event, and they pick up the hotel or vise versa.
-
Local Travel
-
Use the following –
- VMworld Shuttle
- Bus
- Uber
- BART
- Once again hit up those vendors, they might have a way to get you around for free
-
-
Finally here is a breakdown of how I got to so many events and how/who paid for it….
| Year | Pass | Travel | Food | Hotel |
| 2008 VMworld | Vendor Sponsor – Full Pass | Employer Paid | Vendor / Event | Employer Paid |
| 2009 VMworld | VMUG Sponsored – Full Pass | Vendor paid for Airfare with Miles | Vendor / Event | Employer Paid |
| 2010 VMworld | VMUG Sponsored – Full Pass | Vendor paid for Airfare with Miles | Vendor / Event | Vendor Sponsored |
| 2011 VMworld | Vendor Sponsor – Expo Pass but I got an upgrade to Full by asking others | I drove two others and I paid for the fuel | Vendor / Event | Travel Companion paid for room |
| 2012 VMworld | Employee Labs | Employer Paid | Employer Paid | Employer Paid |
| 2013 VMworld | Employee TAM | Employer Paid | Employer Paid | Employer Paid |
| 2014 VMworld | Employee TAM | Employer Paid | Employer Paid | Employer Paid |
Summing it up…
My take is this, if you REALLY want to go you’ll get there but sometimes it takes effort to do so and if you do it right it might not cost you a thing. Don’t let anything stop you and find your way there.
Finally, after you’ve been to the event don’t forget about the folks who got you there and say ‘Thank you’. Then over the next year continue to build this relationship, as you never know if you’ll need help again, or you want to help someone else get there.
Network port diagram for vSphere 5.x – Poster
This is by far and away my favorite VMware Poster and I use it as a reference quite often.
Benefits –
- Clear representation of all the TCP/IP Ports needed by VMware Products and their dependences
- PDF has a very clear diagram that can be printed on to a large format
- PDF Diagram has reference numbers that correlate to further slides for more information
You can find the PDF Here >>http://kb.vmware.com/selfservice/microsites/search.do?language=en_US&cmd=displayKC&externalId=2054806
PIC of the Reference Link –
Part of a PIC of the Port Diagram
vSAN 1.0 Released Home lab update here I come!
In case you missed the vSAN announcement and demo on www.vmware.com/now Here is a quick review…
- General Availability of Virtual SAN 1.0 the week of March 10th
- vSphere 5.5 Update 1 will support VSAN GA
- Support for 32 hosts in a Virtual SAN cluster
-
Support for 3200 VMs in a Virtual SAN cluster
- Note, due to HA restrictions only 2048 VMs can be HA protected
- Full support for VMware Horizon / View
- Elastic and Linear Scalability for both capacity and performance
- VSAN is not a virtual storage appliance (VSA). Performance is much better than any VSA!
- 2 Million IOPS validated in a 32 host Virtual SAN cluster
- ~ 4.5PB in a 32 host cluster
- 13 different VSAN Ready Node configurations between Cisco IBM Fujitsu and Dell available at GA, with more coming soon
Elaboration and analysis: http://www.theregister.co.uk/2014/03/06/vsan_emerges_at_a_whopping_32_nodes_and_two_meeelion_iops/
VSAN Hands-on Labs (already available): https://blogs.vmware.com/hol/2014/03/click-go-take-vsan-hands-labs.html
Cormac as always does a great review as well — http://cormachogan.com/2014/03/06/virtual-san-vsan-announcement-review/
vSAN will be the next direction for my home lab as I plan to move away from in my opinion a buggy FreeNAS product.
High speed networking is required for the replication network and my back plane will be something like this — http://www.bussink.ch/?p=1183
I’ll post up more as it progresses.
Enjoy!
Patches? Patches? We don’t need no stinkin’ Patches
Recently I reviewed some of the patching techniqus around ESXi and vCenter Server.
The question I wanted to know more about was – How are products (vCenter and ESX(i) patched (4.0 and above)?
What I found was “it depends” J but I remember them this way…
Note – Before I apply ANY patch or update I always check the HCL, check with my hardware vendor, and read the release notes as most patches contain prerequisites.
vCenter Server is simple, I remember it this way “Patches? Patches? We don’t need no stinkin’ Patches…”
ESXi — Can be a bit more complicated… It’s more like this — “I’d like the pie heated and I don’t want the ice cream on top, I want it on the side, and I’d like strawberry instead of vanilla if you have it, if not then no ice cream just whipped cream but only if it’s real; if it’s out of the can then nothing.”
Here is a bit more depth –
vCenter Server (VC) Windows Edition –
VC 4.x, 5.0 and 5.1 – There are no patches vCenter Server only full updates packages which contain all the content. AKA – Patches are included in the each releases.
VC 5.5 – No patches for VC just updates but there are patches for tcServer and JRE. These patches will be released on an as needed basis.
It’s pretty simple, if you want to patch your vCenter Server then just install an Update, but do your
homework first.
ESXi —
First off Patches are not exactly cumulative and depending on how you update ESXi the Build numbers and sub-components can be off.
Trying to simplify this… it’s not a cut and dry method but here is what I found…
In most cases (not all) it seems to come down to two ways of updating your host. Ask yourself this:
1. Do you want ESXi to report the more accurate Build Number and have all the underlying sub-components (Virt Hardware, Tools, etc) up to date?
2. OR is it more important to just have a specific Patch installed?
If Yes to “more accurate Build Number” then this is suggested…
Update ESXi to the latest Update, then apply the latest Patch.
This should ensure the sub-components contained within are updated uniformly and the build number should report properly.
Accurate Build Number Example – You are at ESXi 4.1U1, update it to ESXi 4.1U3 first, then Apply Patch 9
The result should yield an ESXi server and sub–components fully up to date
If Yes to “more important to just have a specific Patch” Simple answer is just apply that patch
However depending on your current level of ESXi the patch may not contain all the updated sub-components.
It will contain the Patches and Security updates documented in its KB or release notes.
Specific Patch Example – You are at ESXi 4.1U1, Just Apply Patch 9
The result should yield an ESXi Server with Patch 9 and the sub-components may not be updated, it depends on the patch
This may also change the build number to reflect an unexpected result, meaning it may not look like the build number for ESXi 4.1U1 or Patch 9, it may be somewhere in between.
Last Monkey Wrench in this mix… Express Patches with ESXi
This is the exception to the statements above and add a couple of new rules…
Express Patches typically fix only a very specific function, and they are typically are NOT cumulative.
Monkey Wrench Example – You are at ESXi 4.1U1 let’s say Express Patch 3 (EP) is the latest patch level.
To fully update ESXi and Sub-components you should update to ESXi 4.1U3 first, apply the Patches and only EP’s just below EP3, then apply EP3
If you only want the EP then just apply EP3
Hopefully this makes sense and after reading this thread I’ll bet you never look at ESXi patching the same way J
One last item here is a great url around build numbers…
vSphere 5.x licensing Matrix
Ever want to compare a full list of the vSphere features to the associated licensing level?
Well now you can… Check out >> http://kb.vmware.com/selfservice/microsites/search.do?language=en_US&cmd=displayKC&externalId=2001113
Here is a quick snapshot of the matrix. Enjoy!
vSphere 5.x licensing Matrix
Ever want to compare a full list of the vSphere features to the associated licensing level?
Well now you can… Check out >> http://kb.vmware.com/selfservice/microsites/search.do?language=en_US&cmd=displayKC&externalId=2001113
Here is a quick snapshot of the matrix. Enjoy!
vmexplorer
